James Barretta is a licensed Florida architect (License # AR0017415) and founder of Barretta and Associates LLC in Delray Beach, who creates clear drawing sets that are both code-compliant and designed for residential and commercial properties in Palm Beach County and throughout Miami-Dade.
Each drawing we deliver is signed and sealed by a licensed architect that has met the submission requirements of your particular building department and the Florida Building Code. Each municipality may have their own standards. From concept to permit-ready construction documents for a custom home, renovation, or commercial build-out.
A full architectural drawing set is more than floor plans. Building departments require a complete package before plan review begins. An incomplete submission resets your timeline. Barretta and Associates LLC prepares every document the permit office requires on the first submission.
A standard residential or commercial drawing package from our office includes:
Commercial and institutional projects add occupancy separation drawings, ADA accessibility routes, and product approval documentation for HVHZ-rated assemblies where applicable. We scope every project before drafting begins so you’re not paying for sheets you don’t need.
Founder, Barretta Associates
Every service is performed by professionals who work towards the highest standards.
Every project at Barretta Associates follows a defined sequence. Each step ends with something you review and approve before we proceed. No surprises.
James Barretta reviews your project scope, site address, zoning, and budget before any agreement is signed. You'll know what your property can accommodate and what the drawing process will cost before you commit to anything.
We produce initial layout drawings for your review. These establish the spatial concept: where rooms sit, how the building meets the site, and what the overall massing looks like. You revise. We redraw. We continue until the concept is confirmed.
All dimensions, materials, wall types, and structural choices get locked in. Your contractor uses these drawings to produce a reliable bid before you've committed to construction costs.
We prepare the full permit-ready drawing set, coordinating with structural and MEP engineers at every sheet. Every drawing carries James Barretta's signed and sealed Florida architect credentials, satisfying Florida Department of Business and Professional Regulation requirements for building permit submission.
Architectural drawings are not a single product. Your project moves through defined phases, and the drawings produced at each phase serve a different purpose. Mixing phases up front wastes money. Skipping a phase risks rejection at the building department.
Schematic drawings are used to develop a basic concept: the layout of the spaces, the general massing of the building, and the relationship between rooms and exterior areas. These are the sketches you look at, edit, and approve before we spend drafting time refining the detail. They're precise enough to confirm your vision and flexible enough to change without significant cost.
Design development drawings lock in the specifics. Room dimensions, door and window selections, wall types, exterior materials, and structural system choices all get resolved at this phase. By the end, your project has a defined shape and the scope your contractor needs to produce a reliable construction estimate before you've committed construction dollars.
Construction documents are the permit-ready set. Every sheet carries James Barretta's Florida architect seal and signature, satisfying the requirement under Chapters 471 and 481 of the Florida Statutes. These drawings go to the building department for plan review and to your contractor for field use. We coordinate with structural, mechanical, electrical, and plumbing engineers during this phase so the full set is internally consistent and passes plan review as submitted.
We create professional architectural concepts that combine creativity, practicality, and compliance with local building standards.
Detailed architectural drawings prepared for contractors, builders, and city approvals. Our plans are clear, accurate, and ready for construction.
From office layouts to commercial buildings, we design spaces that maximize efficiency, safety, profitability and aesthetics.
Navigating city permits can be complex. We guide clients through the permitting process to ensure faster approvals and fewer delays.
Understanding zoning regulations is critical for any project. We help determine what is allowed on your property and assist with zoning compliance.
At Barretta Associates, every project begins with understanding your ideas, needs, and goals. We create architectural designs that are not only visually appealing but also practical and compliant with local building regulations.
Our team focuses on delivering custom solutions for residential and commercial projects, ensuring every design reflects the client’s vision while meeting zoning and permitting requirements.
From the initial concept to finalized drawings, we work closely with you to make the entire process smooth, efficient, and stress-free.
Work with an experienced architectural professional who understands design, functionality, and building compliance to bring your project to life.
We design projects that align with your financial goals while maintaining high standards of quality and creativity.
Discuss your project with us and receive professional guidance on design, zoning requirements, and the permitting process before getting started.
Turn your ideas into professionally designed spaces with Barretta Associates. We specialize in architectural designs, detailed drawings, and assistance with permitting and zoning requirements to help your project move forward smoothly.
Whether you are planning a residential project or commercial development, our goal is to create practical, compliant, and visually appealing designs tailored to your needs.
We needed architectural drawings for a commercial renovation, and Barretta Associates delivered exactly what we needed. Great communication and very knowledgeable about local permitting.”
Barretta Associates provides professional architectural design services, architectural drawings, commercial design solutions, permitting assistance, and zoning guidance for residential and commercial projects.
Yes, we assist clients with the permitting process by preparing the required architectural drawings and helping ensure the project meets local building codes and regulations.
Barretta Associates serves clients throughout South Florida helping homeowners, contractors, developers, and business owners with their architectural needs.
Getting started is simple. You can call us or send an email to discuss your project details, and we will guide you through the next steps for design, drawings, and permitting.
Have a project in mind or need professional architectural guidance? The team at Barretta Associates is here to help. Whether you need architectural designs, drawings, permitting assistance, or zoning guidance, we are ready to discuss your ideas and provide the right solutions.
Reach out to us by phone or email, and we’ll be happy to answer your questions and help you get started on your project.
Have questions about your project or need professional architectural services? Contact Barretta Associates today. Our team is ready to assist you with architectural designs, drawings, permitting, and zoning guidance. Reach out by phone or email and let’s discuss how we can help bring your project to life.
